NH3 Analyzer

Ammonia analyzer adopts chemiluminescence principle to detect ammonia gas in ambient air. It is equipped with external ammonia reformer and sampling system. The range can be selected between O-500ppb and 0-2000ppb.

  • CPCB Approved Technology
  • TUV Certified
  • US EPA Compliant
  • Advanced Chemiluminescence Technology for Accurate NH3 Monitoring
  • High accuracy: Ppb-ppm level
  • Reliable & stable Performance
  • Smart & User Friendly Operation
  • Ideal for CAAQMS & Industrial Monitoring

The ammonia analyzer is able to reduce ammonia gas absorption through control of internal sampling gas flow and processing of sampling gas path to ensure the response time as well as accurate control of concentration.

During operation process, sample gas passes through external reformer first. The analyzer converts NH3 into NO under effect of catalyst. With the original NO in air, it will display total concentration value of NO. In next cycle period, the analyzer measures NO concentration in air. The difference between the above two values is the concentration of NH3.

  • Measuring range: 0-500ppb or 0-2000ppb (selectable) O3 device can adjust O3 generating concentration as required
  • Respectively display concentration of NH3, NO, NO2 and NOX
  • Timed dark current compensation
  • Continuous self-inpection with alarm function
  • O3 generator with osmotic drying pipe
  • Compensation function for temperature and pressure.
  • Bidrection RS-232 port for remote control.
  • Colorful display and screen touch operation.
  • Large-capacity memory; store historical data automatically.
  • Response Time : 120s
  • Ambient Air Quality Monitoring
  • Industrial Emission Monitoring
  • Pollution Source Monitoring
  • CAAQMS Applications
